Announcements:
·
Room: ENGMC 627
·
Time: Tuesday and Thursday
10:00am-11:25pm
·
TA Office hour: Thursday 1 to 2pm @
McConnell Building Rm 707
·
There are no classes on 10/24, 11/09, and 11/28.
·
Final project topics are posted (10/05)
Ø
Please take your time to research and choose a topic that interests you
the most. There are many topics so the chances are that you will get your
favorite one. You have one week to decide on which topic to work on. Please
submit 3 topics and indicate your preference to jay.sing@gmail.com on Oct. 12.
Ø
Please read the proposed approach on preparing the final project.
Remember to submit 5 references by Oct. 26.
·
Final project topics are assigned (10/11)
·
Assignment #2 is posted (10/11)
·
Assignment #3 is posted (11/01)
·
Final presentation will be on Nov. 30th and the schedule is posted
below (11/08)
·
Final project is due on Dec. 10th.
Ø
Class 01 (09/05)
Ø
Class 02 (09/07)
Ø
Class 03 (09/12)
Ø
Class 04 (09/15)
Presentation Schedules: (presentation
guide)
·
Two
terminal devices (updated 09/21)
·
Three terminal devices
Ø
HBT (updated 09/21)
Ø
pHMET (updated 09/21)
Final Project:
Ø
Jane: Microwave oscillators
Ø
Guillaume: The evolution and current status of PHEMT
technology
Ø
Hadley: Principles and status of RFID
Ø
Li: Principles of GPS and GPS
receiver
Assignments:
·
Assignment #1: Create an ADS project by following Demo. Hand in a brief report (max. 5 pages)
including a schematic design, a momentum layout, and the results
(S-Parameters). (Due on Oct 9th @ 5pm by email)
·
Assignment #2: Follow the “Approximate
Graphical Synthesis” (handout)
method to design a 50 Ohm microstrip line at 10 GHz. Given the substrate (SiO2)
thickness, h, is 500 um
and the substrate permittivity (er) is 4. Assume the metallization layer is a perfect
conductor. Use ADS to optimize the
transmission line to be 50 Ohm +/- 1% at 10 GHz. Hand in a brief report (max. 5 pages) including
analytical calculation, a momentum layout, an impedance (Zo) vs
frequency graph, and a short discussion on the results obtained. (Due on
Oct. 30th by
email – jay.sing@gmail.com) NOTE:
in step (b) fix the value of Zo, in step (d) fix the value of er.
·
Assignment #3: Use the transmission line obtained in
Assignment 2, match the LOAD (15 - j50 Ohm) to the characteristic
impedance of the line. It is desirable to
do this to obtain the maximum power transfer between the source and the
load. Assume lossless transmission line,
you can use any techniques to match the line (single stub matching
technique is one method, refer to chapter 9 in “Field and Wave Electromagnetics” by Cheng), provided that
the reflection coefficient (S11) looking into the line has to be below –15
dB at 10 GHz.
Hint: Use “tune parameters” in the schematic window to
make the tuning easier. Press the button
and then select the parameters you want to tune on the schematic, ie, the
length of transmission line. If short
circuit stub is used for matching, remember to ground the short circuit stub in
the layout window. (Refer to chapter 9
in “Field and Wave Electromagnetics” by Cheng for preliminary calculation
designs)
Compare the results obtained from the schematic to the layout. Include in the report (max. 8 pages) the schematic design, layout design, impedance vs. frequency graph, and S11/S21 results. (Due on Nov. 19th by email – jay.sing@gmail.com)
Please send
